Living Museum of the Great Western Railway

1466 / 4866 - 48xx/14xx Class

95 of these 0-4-2T's were built to replace the somewhat similar 517 class which, by 1932, were being scrapped in large numbers. Essentially a 19th century design with detail improvements, they were fast and popular, if somewhat ancient in appearance. They served the GWR and BR well, only being withdrawn when their particular branch line closed or was dieselized. The first 75 were fitted for auto-train working, whereby the train can be driven from a cab in the leading coach when the engine is working in the pushing direction. Nos. 4800-4874 were re-numbered 1400-1474 in 1946, to make way for 28xx class engines being converted to oil-burning, which required their numbers.

Built at Swindon in February 1936, 4866 was a particularly strong, free-running member of the class. It was based at Newton Abbot almost all its working life, transferring to Taunton at the very end. Selected for preservation, it was bought in April 1964 for £750, and delivered to the Society's Totnes depot. Here it again became popular, this time with the local children, who would flock to see it operating. The Society's first engine, it has generally been in working order all its life, and ran in steam to Didcot from Plymouth in November 1967, on establishment of Didcot Railway Centre. More details and pictures of the journey is available in a GWS Echo Article (1.6Mb .pdf file) of the time.

Shortly before the second world war, 4866 achieved some notoriety. Whilst standing in Newton Abbot station its crew saw a train bearing down on them on their track. They set the engine in motion, the fireman jumped and the driver was flung off with the impact. 4866 did not hang around, and was routed driverless on to the Kingswear line where it ran on for seven miles until purposely derailed between Torquay and Paignton.

4866 has spent all its life since 1946 running as No. 1466. Following light repairs during 1998 it was repainted to its original livery and re-entered service at Easter 1999 as 4866.

1466 was withdrawn from service in 2000 due to the condition of its foundation ring.

In June 2013 1466 was repainted into BR black livery in connection with a series of photo-charters.

Restore 1466 to full working order

Wouldn’t it be wonderful if 1466 could be overhauled in time to celebrate the 60th anniversary of the Great Western Society in 2021?

Mechanically the engine is in reasonable condition, but it is known that a new backplate, firebox side plating and possibly a new boiler barrel will be needed.

No 1466 left Didcot in early December 2018 for contract overhaul at Western Steam Engineering, operated by Ed Freeman, a former volunteer at Didcot.

The cost of the overhaul is estimated at around £300,000, of which £190,000 is currently in the fund. The shortfall of £110,000 is to be raised over the duration of the overhaul. If you would like to contribute please send a cheque made out to the ‘Great Western Society 1466 Fund’ to Richard Croucher at Didcot Railway Centre, Didcot, OX11 7NJ. If you are also able to Gift Aid the amount, please complete and return the Gift Aid Declaration (102kb .pdf file) with your donation.

Download the 1466 appeal leaflet (688 kb .pdf file) for more information.

Under Overhaul
Build date
Built at
Wheel arrangement
0 - 4 - 2 T
Route availability
All Routes
Barrel diameter
3 feet 10 inches
Barrel length
10 feet
Boiler pressure
165 lbs/sq in
Boiler type
Group 7
Coal capacity
2.75 tons
(2) 16 x 24 inches
Heating surfaces, firebox
83.2 sq ft
12.8 sq ft
Power class
Superheater area
Tractive effort
13,900 pounds
Heating surfaces, tubes
869.8 sq ft
Water capacity
800 Gals
41 tons 5 cwt.
Wheel diameter
5 feet 2 inches
